Heavy Duty Stopper Cylinder RS2H
-
- ・Weight: Reduced by up to 22% (Compared with the previous RS1H series)
-
- ・Cylinder tube: Shortened by up to 9 mm (RS2H63-30 stroke)
-
- ・Capable of stopping pallets softly
-
- ・Stopper cylinder with shock absorber
・Lock Release specification (-XC102)
Features & Compatibility
■Light weight / compact
Weight: Reduced by up to 22%
Cylinder tube: Shortened by up to 9mm
■Easy replacement of shock absorbers
Replaceable just by loosening the set screw
■Stop the workpiece gently with adjustable shock absorber.
Resistance value can be adjusted by rotating the adjustment dial.
■Better handling and visibility of the lock mechanism (Option)
The shape of the lock is changed. Easy to unlock manually,
and instantly see whether it is locked.
■Mounting is interchangeable with the current RS1H series.
Cylinder mounting pitch and the height from the mounting
surface to the roller center are interchangeable with the RS1H series.
■Compact auto switch (D-M9□) and magnetic
field resistant auto switch (D-P3DW) can be
mounted to three sides.
field resistant auto switch (D-P3DW) can be
mounted to three sides.
Compact auto switch can be directly mounted to round switch mounting groove.
■Piping is available from 2 directions.
■The roller can be selected from two materials to suit the application.
(Resin, Carbon steel)
(Resin, Carbon steel)
■The roller lever direction can be changed in 90° steps.
To adapt the roller lever of the stopper to the work piece direction,
the roller lever can be positioned in 4 different directions in 90° steps around the piston rod.
■Options
■Series Variations
